12W7AE-3 | مضخم صوت 12 بوصة
Anniversary Edition W7 Series 2000W 12" 3-ohm Subwoofer
Enjoy a complimentary $75 Installation credit on all Online Orders. Limit one per customer. Terms and Conditions apply.
Need Help?
مشغل مضخم الصوت مقاس 12 بوصة (300 مم)، 3 أوم
12W7AE-3
إصدار الذكرى السنوية العاشرة - مضخم صوت W7 مقاس 12 بوصة (1000 واط، 3 أوم)
يقدم الطراز 12W7AE أداءً جديًا على الطاولة من خلال الجمع بين اختراق تصميم W7 للرحلات الطويلة مع التجويف الكبير مقاس 12 بوصة. لقد أطلق عليه بعض أقوى المراجعين في العالم لقب "الإدمان" و"المغري" و"مرجع مضخم الصوت الجديد"، وقد حصل على هذه الأوسمة من خلال تقديم ديناميكيات لا حدود لها تقريبًا وتوازن استثنائي وجودة صوت عالمية المستوى.
من الأفضل استخدام هذا المحرك القوي مع طاقة مكبر الصوت في نطاق 400 وات - 1000 وات وهو مُحسّن للعمل في 1.375 متر مكعب. قدم (38.9 لتر) حاوية محكمة الغلق، أو 1.75 متر مكعب. قدم (49.6 لتر) حاوية مستوردة.
تحتفل مكبرات الصوت W7AE (إصدار الذكرى السنوية) بالذكرى العاشرة لإطلاق مكبرات الصوت W7. من الناحية الوظيفية، فهي متطابقة مع W7 الأصلية، ولكنها تتميز بالاختلافات الشكلية التالية:
- سلال مطلية بمسحوق الساتان الأسود
- حلقة المشبك المحيطي بأكسيد مشرق
- شارة مخروطية لطبعة الذكرى السنوية
- تسمية المحطة الطرفية لإصدار الذكرى السنوية
المواصفات العامة
| المواصفات العامة |
|
|---|---|
| التعامل المستمر مع الطاقة (RMS) | 1000 واط |
| قوة مكبر الصوت الموصى بها (RMS) | 400 - 1000 واط |
| الممانعة الاسمية (زنوم) | 3 أوم |
| المواصفات المادية |
|
| القطر الاسمي | 12.0 بوصة / 300 ملم |
| القطر الكلي (أ) | 12.5 بوصة / 318 ملم |
| قطر ثقب التركيب (ب) | 10.5 بوصة / 267 ملم |
| قطر دائرة ثقب الترباس (C) | 11.27 بوصة / 286 ملم |
| القطر الخارجي للمحرك (د) | 7.5 بوصة / 191 ملم |
| عمق التركيب (E) | 9.5 بوصة / 241 ملم |
| إزاحة السائق | 0.14 قدم مكعب / 4.0 لتر |
| الوزن الصافي | 45 رطل/20.4 كجم |
| حدود | |
| الرنين الهوائي الحر (Fs) | 27.2 هرتز |
| الكهربائية "س" (QES) | 0.514 |
| الميكانيكية "Q" (Qms) | 7.807 |
| إجمالي مكبر الصوت "Q" (Qts) | 0.482 |
| الامتثال المعادل (فاس) | 2.33 قدم مكعب / 66.0 لتر |
| رحلة خطية في اتجاه واحد (Xmax)* | 1.15 بوصة / 29 ملم |
| الكفاءة المرجعية (لا) | 0.25% |
| الكفاءة (1 وات / 1 م)** | 86.2 ديسيبل SPL |
| منطقة المكبس الفعالة (Sd) | 84 بوصة مربعة / 0.0542 متر مربع |
| مقاومة التيار المستمر (إعادة) | 2.47 أوم |
| * يتم اشتقاق مواصفات Xmax عبر طريقة تراكب الملف الصوتي في اتجاه واحد دون تطبيق أي عوامل تصحيح. ** الكفاءة (1 وات / 1 م) ليست مؤشرًا دقيقًا لقدرة خرج مكبر الصوت ولا ينبغي استخدامها كمقارنة بمكبرات الصوت الأخرى لتحديد أي منها "أعلى صوتًا". |
|
| مواصفات العلبة المختومة |
|
| سمك الحائط | 0.75 بوصة / 19 ملم |
| سمك الحاجز الأمامي | 1.0 بوصة / 25 ملم |
| الحجم (صافي كثافة العمليات) | 1.375 قدم مكعب / 38.94 لترًا |
| العرض الخارجي (ث) | 15 بوصة / 381 ملم |
| الارتفاع الخارجي (ح) | 15 بوصة / 381 ملم |
| العمق الخارجي (د) | 16.125 بوصة / 410 ملم |
| F3 | 40.4 هرتز |
| نادي | 44.7 هرتز |
| كيو تي سي | 0.791 |
| مواصفات العلبة المنقولة |
|
| سمك الحائط | 0.75 بوصة / 19 ملم |
| سمك الحاجز الأمامي | 1.0 بوصة / 25 ملم |
| الحجم (صافي كثافة العمليات) | 1.75 قدم مكعب / 49.6 لتر |
| العرض الخارجي (ث) | 22.75 بوصة / 578 ملم |
| الارتفاع الخارجي (ح) | 15 بوصة / 381 ملم |
| العمق الخارجي (د) | 15.875 بوصة / 403 ملم |
| عرض منفذ الفتحة الداخلية (SW) | 1.875 بوصة / 48 ملم |
| ارتفاع منفذ الفتحة الداخلية (SH) | 13.5 بوصة / 343 ملم |
| طول منفذ الفتحة الداخلية (SL) | 24.75 بوصة / 629 ملم |
| طول امتداد المنفذ (EL) | 7.9375 بوصة / 202 ملم |
| ضبط التردد (أف ب) | 36.7 هرتز |
| F3 | 32.8 هرتز |

JL Audio 12W7AE-3 Anniversary Edition W7 Series 12" 1000W RMS (2000W Peak Power Handling) 3 Ohm, Single Voice Coil Component Car Subwoofer
Experience unmatched, room-shaking bass with the JL Audio 12W7AE-3 Anniversary Edition Subwoofer. Engineered for true bass enthusiasts, this 12-inch single voice coil subwoofer delivers up to 1000W RMS and 2000W peak power, giving you deep, powerful, and distortion-free low frequencies. Built with JL Audio’s legendary craftsmanship, it features a polypropylene cone, durable polyester foam surround, and a long-excursion design that ensures tight, accurate bass response from 18 Hz to 200 Hz. With a mounting depth of 9.5 inches and a 10.5-inch cutout diameter, installation is convenient in a wide range of setups—sealed or ported enclosures.
The 10th Anniversary Edition elevates performance and style with a satin-black finish and premium cosmetic touches while preserving the iconic W7 sound signature. Its efficient 3-ohm impedance pairs seamlessly with most high-quality amplifiers, making it a versatile and powerful upgrade for any serious audio system.
Key Features:
-12-inch long-excursion Anniversary Edition subwoofer delivering deep, powerful bass with 1000W RMS and 2000W peak handling
-Efficient 3-ohm SVC design and upgraded Anniversary aesthetics, compatible with sealed or ported enclosures
What's Inside?
- • One 12" Single Voice Coil Subwoofer (attached to an MDF baffle board with 12 Phillips-head screws)
