Rockford Fosgate Power T400X2ad
Power Series 200W Compact 2-Channel Car Amplifier
Enjoy a complimentary $75 Installation credit on all Online Orders. Limit one per customer. Terms and Conditions apply.
Need Help?
Amplificador de 2 canales Clase AD de potencia de 400 vatios
T400X2ad
El Power T400X2ad es un amplificador estéreo ultracompacto y de alta eficiencia de 400 vatios. Cuenta con potencia constante de impedancia múltiple, detección de clip de entrada/salida, controles montados en la parte superior y enfriamiento por inducción forzada con doble ventilador. Perfecto para automóviles híbridos, eléctricos, pequeños, camiones, motocicletas y UTV de lado a lado.
¿Qué hay en la caja?
| ⬥ Amplificador de potencia |
| ⬥ Conector(es) de entrada Molex de RCA a 4 pines |
| ⬥ Conector(es) de altavoz Molex de 4 pines y 16 AWG |
| ⬥ Conector de alimentación |
| ⬥ Guía de configuración rápida |
| ⬥ Manual de instalación y funcionamiento |
| ⬥ CD de operación (Tonos de prueba y manual de instalación) |
Características
⬥ Tecnología Clase AD propiedad de Rockford Fosgate
⬥ Función de salida remota cuando se utilizan entradas de alto nivel
⬥ Conector de alimentación/tierra de 8 AWG con conectores RCA mejorados
⬥ Potencia constante de impedancia múltiple de 4/2 ohmios
⬥ Entradas diferenciales con función de encendido automático de alto nivel
⬥ Capacidad de puente de 4 ohmios
⬥ Controles montados en la parte superior
⬥ 2013 PLC2 listo para control remoto
⬥ LED indicadores y de detección de clip de entrada/salida CLEAN
⬥ Refrigeración por doble ventilador
⬥ Detección térmica en tiempo real
⬥ Disipadores de calor dobles extruidos
⬥ Tecnología de montaje en superficie discreta
Especificaciones generales
| Cumple con Cta-2006 | |
| número de canales | 2 |
|
Poder total (Suma de potencia nominal) |
400 vatios |
|
Potencia nominal (potencia continua RMS) |
200 vatios x 2 a 4 ohmios 200 vatios x 2 a 2 ohmios 400 vatios x 1 a 4 ohmios en puente |
|
Poder dinámico (PVC/PowerCube®) |
223 vatios x 2 a 4 ohmios 248 vatios x 2 a 2 ohmios 449 vatios x 1 a 4 ohmios en puente |
| Puenteable | Sí Terminales: Izquierda (+) Derecha (-) |
| Respuesta frecuente | 20Hz - 20kHz +/-1dB |
| Sensibilidad de entrada | 150mV a 12V |
| Clase de topología de circuito | Clase AD |
| Eficiencia (media) | >75% |
|
Distorsión armónica total (THD+ruido) |
4 ohmios: <1,0% 2 ohmios: <1,0% |
| Entrada de señal | Entrada de nivel alto/bajo: arnés de 4 pines |
| Salida de señal | - |
| Controles de tono | Agudos: 0 a +14 dB a 12,5 kHz Graves: 0 a +18 dB a 45 Hz |
| Controles cruzados | Paso alto: 50 Hz - 250 Hz a 12 dB/octava Butterworth Paso bajo: 50 Hz - 250 Hz a 12 dB/octava Butterworth Pase total: Sí |
| Controles remotos | PLC2 opcional proporciona control del nivel de perforación |
| Indicadores visuales | Energía: LED azul Proteger: LED rojo Clip de entrada: LED3 rojo Clip de salida: LED azul/violeta/rojo1,2,3 Leyenda de colores LED: 1AZUL: <0,5% THD 2VIOLETA: 1% THD 3ROJO: 10%+ THD |
| Calibre del cable de alimentación | 8 AWG |
| Conector de entrada de alimentación | Terminal de compresión desmontable Reemplazo 1040-57997 |
| Calibre del cable del altavoz | 16 CAE |
| Conector de salida del altavoz | Arnés de 4 pines |
| Enfriamiento | Refrigeración por ventilador doble |
| Disipador de calor | |
| Tensión de funcionamiento | 9 - 16 VCC |
|
Fusible recomendado (no incluido) |
60 A |
| Consumo de corriente promedio (música de 13,8 V) | 23A |
| Máx. Consumo de corriente (onda sinusoidal de 13,8 V) | 45 A |
| Alternador sugerido | 75 A |
| Dimensiones (Alto x Ancho x Fondo) | 1,6 x 4,3 x 7 (pulg.) 4,1x10,8x17,8 (cm) |
| Peso de envío | 2,9 libras. (1,31 kilos) |
