Hertz DCX 570.3
Dieci Series 5"x7" 2-way car speakers
Enjoy a complimentary $75 Installation credit on all Online Orders. Limit one per customer. Terms and Conditions apply.
Free Shipping on all orders nation wide
Free Return on all orders
Need Help?
Hertz DCX 570.3 | Dieci Series 5" x 7" Two-Way Coaxial Speakers
The Hertz DCX 570.3 is a high-efficiency coaxial speaker designed to provide premium sound quality with minimal installation effort. Part of the acclaimed Dieci series, these speakers feature a neodymium magnet and a PEI dome tweeter to ensure a detailed high-frequency response. Engineered with a lightweight yet rigid structure, they deliver a linear frequency response and high sensitivity, making them an excellent choice for upgrading factory systems in vehicles that utilize 5x7 or 6x8 inch mounting locations.
Product Highlights
Water-Repellent Pressed Paper Cone: The woofer utilizes a water-repellent treated paper cone, which provides a natural sound while ensuring durability against the humidity often found inside car doors. This stiff, lightweight material allows for accurate mid-bass reproduction and a smooth transition to the higher frequencies.
PEI Dome Tweeter with Neodymium Magnet: High frequencies are handled by a 15mm (0.6 in.) PEI dome tweeter. Driven by a high-energy neodymium magnet, this tweeter offers superior high-frequency extension up to 21 kHz and excellent off-axis dispersion, ensuring clear sound throughout the vehicle's cabin.
TPU (Thermoplastic Polyurethane) Surround: The woofer cone is supported by a TPU surround, which is designed for wide linear excursion and resonance damping. This material helps maintain sound purity even at high volumes, reducing unwanted vibrations and distortion.
High Sensitivity Design: With a sensitivity rating of 93 dB, the DCX 570.3 is extremely efficient. This allows the speakers to produce significant volume and clarity even when powered by a standard factory head unit, providing a substantial performance boost without the immediate need for an external amplifier.
Key Features
Built-In Crossover: The integrated passive crossover ensures a seamless blend between the woofer and the tweeter. This built-in design simplifies the installation process by eliminating the need for external boxes or complex wiring.
Pure Copper Voice Coil: Wound on a conex former, the 1-inch (25 mm) pure copper voice coil is designed for maximum lightness and thermal stability, allowing for reliable performance during long, high-volume listening sessions.
Large Motor Assembly: Despite its compact design, the speaker features a large motor assembly with a high-density flux ferrite magnet. This provides the necessary force for precise voice coil control and punchy low-frequency output.
Optimized Dimensions: The 2.6-inch (66 mm) mounting depth and standard DIN-size basket make these speakers compatible with a wide range of Ford, Mazda, and Chrysler vehicles that use 5x7 or 6x8 inch factory speaker openings.
Technical Specifications
| Feature | Specification |
| Model Number | DCX 570.3 |
| Speaker Size | 5 x 7 in. (also fits 6 x 8) |
| Power Handling (Peak) | 120 Watts |
| Power Handling (Continuous) | 60 Watts RMS |
| Impedance | 4-Ohms |
| Frequency Response | 60 Hz – 21,000 Hz |
| Sensitivity | 93 dB SPL |
| Mounting Depth | 2.6 in (66 mm) |
What’s In The Box?
-
(2) Hertz DCX 570.3 2-Way Coaxial Speakers
-
Mounting Screws and Speed Clips
-
Owner's Manual and Warranty Information
-
(Note: Grilles are typically not included for this model)
Hertz DCX570.3 Dieci Series 5x7" 60W RMS (120W Peak Power Handling) 4 Ohms, 2-Way Coaxial Car Speakers (pair)
Hertz DCX570.3 5x7-Inch Coaxial Car Speakers
Upgrade your car audio with the Hertz DCX570.3, a 5x7-inch coaxial speaker system designed for clear, dynamic, and reliable sound reproduction. Engineered with precision, these speakers deliver accurate and controlled bass, smooth highs, and an immersive listening experience, making them a perfect choice for a wide range of vehicles.
Accurate and Controlled Bass Response
The DCX570.3 features a pressed-paper woofer cone with water-repellent treatment, ensuring precise, tight, and distortion-free bass. Paired with a PEI dome tweeter, it reproduces detailed high frequencies, delivering a well-balanced and natural sound across all audio ranges.
Power Handling and Efficiency
Capable of handling up to 60W RMS (120W peak), these speakers provide robust and dynamic output while maintaining clarity. With a sensitivity of 93 dB, they produce efficient sound even with lower amplifier power, making them ideal for both factory and aftermarket systems.
Compact, Versatile, and Easy to Install
Designed to fit standard 5x7-inch openings, the DCX570.3 is compact and versatile, allowing hassle-free installation in most vehicles. Its durable construction ensures long-lasting performance, while the carefully engineered design provides a pleasant listening experience across all music genres.
Physical Specifications
– A1: 220 mm (8.7 in.)
– A2: 141 mm (5.6 in.)
– B1: 182 mm (7.2 in.)
– B2: 127 mm (5 in.)
– C: 66 mm (2.6 in.)
– D: 59 mm (2.3 in.)
Key Features
– 5x7-inch coaxial design for wide compatibility
– Pressed-paper woofer cone with water-repellent treatment for accurate bass
– PEI dome tweeter for smooth, detailed highs
– Handles 60W RMS / 120W peak power
– Sensitivity: 93 dB for efficient sound production
– Balanced, immersive sound across all music genres
– Compact and versatile design for easy installation
– Durable construction for long-lasting performance
What's Inside?
- (2) 5x7" 4 Ohms, 2-Way Car Speakers
- (8) 3/4" Screws
- (8) Speed clips
- Owner's manual (English/ Spanish/ French/ German/ Italian/ Portuguese/ 20 Others)
